Page 216 Speed Level Series - Service & Parts Manual
January 2019Section 13 - Boom
Item Part Number Description Qty.
1 7292 Bearing, Sleeve, Bronze, .625 X .500 LG 2
2 18074 Pin, 1.250 X 8.00 2
3 18151 Keeper Pin 2
4 18152 1/2” Pin Retainer 1
5 18165 Keeper Pin .375 x 2.20 2
6 19087 Axle Lock Cylinder 2
7 19103 Module Mount 1
8 19104 Module Mount 1
9 19105 Module Mount 1
10 19106 Module Mount 1
11 19119 Pin, 1.250 X 11.50 2
12 19120 Pin, 2.000 X 11.50 1
13 19157 Boom Wear Pad 1
14 19162 Cylinder Guard 2
15 19550 Front Axle 1
16 19557 Rear Axle Cover 2
17 19568 LH Yoke 1
18 19569 RH Yoke 1
19 19571 Tie Rod 1
20 19577 Chassis 1
21 19579 RH Air Filled Tire 2
22 19580 LH Air Filled Tire 2
23 26057 King Pin Weldment 4
24 50000 WSHR M06 ZP Standard Flat 4
25 50002 WSHR M10 ZP Standard Flat 4
26 50006 WSHR M10 ZP Nordlock 40
27 50007 WSHR M12 ZP Nordlock 1
28 50028 HHCS M06-1.00X020 08 ZP F 4
29 50033 HHCS M10-1.50X025 08 ZP F 4
30 50034 HHCS M10-1.50X030 08 ZP F 8
31 50040 HHCS M12-1.75X035 08 ZP F 1
32 50047 NNYL M06X1.00 08 ZP Nylock 2
33 50125 HHCS M06-1.00X055 08 ZP F 2
34 50172
PCLV 0.500X1.38 ZP STL 2
35 50177 Cotter Pin 0.156X1.75 ZP STL Extprng 2
36 50365 NLUG 09/16-18 08 ZP Hex Lug Nut 36
37 50372 BHCS M08-1.25X025 08 ZP P 2
38 50398 NLOC 05/08-11 05 ZP Top LOC 2
39 50440 SHCS M10-1.50X040 12 ZP F 32
40 50443 WSHR 05/08 ZP Standard Flat 4
41 50477 HHCS 05/08-11X04.00 08 ZP 2
42 83231* Motor & Drive Side Port Assy 2
43 83231* Motor & Drive Side Port Assy 1
44 83231* Motor & Drive Side Port Assy 1
45 91019 Steer Cylinder 2
46 92098 Nut Clip M10 X .375 4
47 92202 PG Trionic Can Tilt 162 1
48 92341 1.51”X3.5”X3/16” Thrust Washer 2
49 92360 1.50 X 1.75 X 1.50+/-.01” Polygon Bearing 4
* See page 217 for individual drive parts
