Page 224 Speed Level Series - Service & Parts Manual
January 2019Section 14 - Axles
Item Part Number Description Qty.
-- 83084 Front Axle Assembly 1
1 19008 Front Axle Weldment 1
2
91019 Cylinder, Steering 2
90990 Seal Kit, Steer Cylinder (Not Shown) --
3 50172 Pin, Clevis, ½ DIA. X 1 3/8” LG 2
4 50178 Pin, Cotter, .12 DIA. X 1” LG 2
5 19079 Rod, Tie Steering 1
6 50154 Screw, 5/8” - 11. 4” LG, GR 5 2
7 HDW6633 Nut, Lock, 5/8” - 11, GR 5 2
8 40334 Mount, Motor W/Bearings 4
9 9307 Bearing, 1.50 x 1.0 DIA 4
10 40308 Mount, Wheel Motor, RH, Front 1
11 40464 Mount, Wheel Motor, LH, Front 1
12 50012 Screw, M16 X 50, GR 12, Socket Head 16
13 50008 Lock Washer, M16 16
14 50072 Screw, ½”-13, 2.50” LG, GR 8, Socket Head 8
15 HDW8457 Nut, ½”-13, GR8 8
16 10709 Hub 2
17 HDW8568 Nut, 1 1/8” - 18 6
18 50177 Pin, Cotter, .156 DIA. X 1.75” LG 6
19 7292 Bearing 2
20
7300P Motor, Wheel, Hyd. 2
94863
Hyd Drive Motors 160CC
3084RT - From Serial #11800423
2
21 50659 Fitting, MB-MJ-12-8 4
22 50665 Fitting, MB-MJ90-4-4 4
23 92202* CAN Tilt Angle Transducer, (152) 1
24 50017 Screw, M8 x 60 2
25 19197 Guard 1
26 50645 Fitting, MJ-FJX-8-8 2
27 50048 Locknut, M8 2
28 20312 Washer Bearing 8
29 20311 Washer, 2.550 x 1.560 4
30 HDW6676 Wheel Stud 1/2-20 x 1 3/4 LG 1
* For adapter from early style (1-Plug) CAN Tilt to new style (2-Plug) CAN Tilt use 22538
