Page 226 Speed Level Series - Service & Parts Manual
January 2019Section 14 - Axles
Item Part Number Description Qty.
1
91166 Wheel/Tire Assy, LH - 10 PLY - Pneumatic (ANSI Standard) 1
91168 Wheel/Tire Assy, LH - 10 PLY - Foam (ANSI Option) (CE Standard) 1
91578 Wheel/Tire Assy, LH - Non-Marking Pneumatic (ANSI Option) 1
91580 Wheel/Tire Assy, LH - Non-Marking Foam (ANSI, CE Option) 1
91581 Wheel/Tire Assy, LH - Turf Pneumatic (ANSI Option) 1
2
91165 Wheel/Tire Assy, RH - 10 PLY - Pneumatic (ANSI Standard) 1
91167 Wheel/Tire Assy, RH - 10 PLY - Foam (ANSI Option) (CE Standard) 1
91577 Wheel/Tire Assy, RH - Non-Marking Pneumatic (ANSI Option) 1
91579 Wheel/Tire Assy, RH - Non-Marking Foam (ANSI, CE Option) 1
91581 Wheel/Tire Assy, RH - Turf Pneumatic (ANSI Option) 1
Incl 91180 Wheel (Service, No Tire) --
3 50165 Nut, Lug, ½” - 20, GR 5 12
4 REF Front Axle Assembly 1
5 19162 Cover 2
6 19087 Cylinder, Axle Lock 2
7 18074 Pin, Ø1.25” 2
8 -- -- --
9 50033 Bolt, M10 x 25 4
10 19119 Pin, Ø1.25 2
11 19120 Pin, Ø7.0 1
12 18152 Pin Retainer, 0.5 x 3.80 1
13 50039 Bolt, M12 x 30 1
14 50006 Lock Washer, M12 4
15 50007 Lock Washer, M10 1
16 18151 Pin Retainer, .375 x 3.75 4
17 50027 Bolt, M6 x 10 4
18 50068 Washer, M6 Flat 4
REF - Reference
Incl - Included with Assembly
