Page 228 Speed Level Series - Service & Parts Manual
January 2019Section 14 - Axles
Item Part Number Description Qty.
1
91166 Wheel/Tire Assy, LH - 10 PLY - Pneumatic (ANSI Standard) 1
91168 Wheel/Tire Assy, LH - 10 PLY - Foam (ANSI Option) (CE Standard) 1
91578 Wheel/Tire Assy, LH - Non-Marking Pneumatic (ANSI Option) 1
91580 Wheel/Tire Assy, LH - Non-Marking Foam (ANSI, CE Option) 1
91581 Wheel/Tire Assy, LH - Turf Pneumatic (ANSI Option) 1
2
91165 Wheel/Tire Assy, RH - 10 PLY - Pneumatic (ANSI Standard) 1
91167 Wheel/Tire Assy, RH - 10 PLY - Foam (ANSI Option) (CE Standard) 1
91577 Wheel/Tire Assy, RH - Non-Marking Pneumatic (ANSI Option) 1
91579 Wheel/Tire Assy, RH - Non-Marking Foam (ANSI, CE Option) 1
91581 Wheel/Tire Assy, RH - Turf Pneumatic (ANSI Option) 1
Incl 91180 Wheel (Service) --
3 50165 Nut, Lug, ½” - 20, GR 5 12
4 16349 Bottom Hose Cover 2
5 19168 Top Hose Cover 2
6 50010 Screw, M8 x 25 2
7 50001 Washer, Lock, M8 2
8 50051 Nut, M16 4
9 40258 Mount, Motor, Rear Axle, Machined 2
10 50043 Bolt, M16 x 40 8
11 50253 Washer, Lock, 5/8 8
12 50151 Screw, 5/8”-11, 2.25” LG, GR 5 8
13 14773 Hub 2
14 HDW9037 Nut, Castle, M42 X 3 (Service) --
15 50170 Pin, Cotter, .250 DIA. X 3” LG 2
16
91319 Wheel Motor, Hyd W/Brake 2
94863
Hyd Drive Motors 160CC
3084RT - From Serial #11800423
2
9781 Seal Kit 1
91138 Brake Kit 1
17 50659 Fitting, MB-MJ-12-8 4
18 50646 Fitting, MB-MJL-4-4 2
19 50647 Fitting, MB-MJ90L-4-4 2
20 50008 Washer, Lock, M16 8
21 50044 Bolt, M16 x 60 G10.9 8
22 91585
Valve Assembly With Coil (XX84ES Models Only)
3084ES - From Serial #11700100
2
23 HDW6676 Wheel Stud 1/2-20 x 1 3/4 LG 1
Incl - Included with Assembly
