Page 230 Speed Level Series - Service & Parts Manual

January 2019Section 14 - Axles

Item Part Number Description Qty.

-- 91319 Wheel Motor W/Brake --

1 9781 Seal Kit --

1a Incl Dust Seal 1

1b Incl Metal Backup Shim 1

1c Incl Backup Seal 1

1d Incl Shaft Seal 1

1e Incl Small Piston O-Ring Seal 1

1f Incl Small Piston Seal 1

1g Incl Large Piston O-Ring Seal 1

1h Incl Large Piston Seal 1

1i Incl O-Ring Seal 1

1j Incl Body Seal 3

1k Incl Manifold Seal 1

1l Incl Commutator Seal 1

1m Incl O-Ring Seal 1

1n Incl Backup Seal 1

-- -- -- --

2 91138 Disk Kit --

Incl Friction Disk 10

91138 Brake Kit 1

Incl Disk Stamping 9

91138 Brake Kit 1

Incl Thick Disk Stamping 2

91138 Brake Kit 1

Incl - Included with Assembly
