Page 272 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 REF Control Module Weldment -- See “Module Installation” On Page 270 --
2 16154 Bracket, Cross Support 1
3 14896 Block, Slide, Door 4
4 25429 Pad 2
5 16226 Bracket, Control Box 2
6 90749 Plug, Battery Charger Connection 1
7 16229 Bracket, Battery Disconnect 1
8 8841 Switch, Battery Disconnect 1
9 91658 Motor Controller 1
10 19276 Heat Sink 1
11
93173 Fuse 1
93174 Base 1
12 91745 Contactor, Solenoid 48V, 12V Coil 1
13 8368 Diode 1
14 9370 Fluid Level Gauge 1
15 6121 Trim Lock 5 ft.
16 91633 Battery Charger 1
17 93093 Manifold, Leveling -- See Section 5 - Hydraulics 1
18 50237 Screw, Hex M8 x 100 3
19 50048 Nut, M8 Nylock 6
20 50028 Screw, Hex, M6 x 20 14
21 50068 Washer, M6 Fender 15
22 50047 Nut, M6 Nylock 14
23 50150 Screw, 5/16–18 × ¾, GR5 4
24 HDW9200 Plug, ¼ NPT 1
25 HDW7778 Screw, FPH MS 1/4-20 x 12 2
26 HDW8267 Nut,Top Lk 1/4-20 GR C 2
27 50282 Screw, Hex, M8 x 35 2
28 50061 Washer, 5/16 Flat 4
REF - Reference
