Page 276 Speed Level Series - Service & Parts Manual

January 2019Section 16 - Base

Item Part Number Description Qty.

1 REF Weldment, Battery Module -- See “Module Installation” On Page 270 --

2 16974 Panel, Battery Module 1

3 16977 Crossbar, Battery Module 1

4 14896 Block, Slide, Door 4

5 25429 Pad 2

6 -- -- --

7 16983 Battery Holddown 1

8 2987 Holddown Rod 2

9 6110 Wingnut 2

10 91641 Battery, 375 AH, UL16 8

11 16619 Bracket, Battery 1

12 16620 Shelf, Battery 5

13 90898 Battery, 12VDC / 17-18 AH 1

14 HDW5724 Screw, 5/16–18, ¾” LG, GR 5 4

15 -- -- --

16 50068 Washer, M6 Fender 17

17 50047 Nut, M6 Nylock 17

18 50028 Screw, Hex, M6 x 20 18

19 91790 Battery Boot, Red, Positive 8

20 91790 Battery Boot, Black, Negative 8

21 91789 Screw, Hex, M8 x 20 4

22 50030 Nut, M8 Nylock 4

23 50061 Washer, 5/16 Flat 4

24 6121 Trim Lock, 1/4” 26

REF - Reference
