Page 278 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 REF Control Module Weldment -- See “Module Installation” On Page 270 --
2 16154 Bracket, Cross Support 1
3 14896 Block, Slide, Door 4
4 25429 Pad 2
5 16226 Bracket, Control Box 2
6 -- -- --
7 16229 Bracket, Battery Disconnect 1
8 8841 Switch, Battery Disconnect 1
9 -- -- --
10 -- -- --
11 -- -- --
12 -- -- --
13 -- -- --
14 -- -- --
15 16152 Bulkhead 1
16 83071 Hydraulic Manifold -- See Section 5 - Hydraulics 1
17 83093 Manifold, Leveling -- See Section 5 - Hydraulics 1
18 50237 Screw, Hex M8 x 100 3
19 50028 Screw, M6 x 20 8
20 50000 Washer, M6 Flat 4
21 50068 Washer, M6 8
22 50047 Nut, M6 x 1.0 Nylock 8
23 50150 Screw, 5/16–18 × ¾, GR5 4
24 50147 Screw, 3/8 × 1 4
25 HDW7783 Lock Washer, 3/8 4
26 50001 Washer, M8 Flat 5
27 50030 Screw, Hex M8 x 20 5
28 50048 Nut, M8 Nylock 5
29 50047 Nut, M6 Nylock 3
30 -- -- --
31 -- -- --
32 -- -- --
33 6121 Trim Lock 5 ft.
REF - Reference
