Mec Speed Level Series User Manual

Page 282 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 19471 Fuse Block 1
2 91709 Fuse, 300 Amp 1
3 8841 Switch, Battery 1
4 9370 Gauge Level Hyd Tank 1
5 19264 Control Module 1
6 19271 Bracket, Control Box 1
7 19274 Inverter Bracket Option 1
8 19276 Heat Sink 1
9 19441 Top Cover 1
10 19443 Wear Pad, Door 2
11 24146 Door Mount 2
12 50000 WSHR M06 ZP Standard Flat 2
13 50001 WSHR M08 ZP Standard Flat 23
14 50031 HHCS M08-1.25X025 08 ZP F 4
15 50032 HHCS M08-1.25X030 08 ZP F 1
16 50034 HHCS M10-1.50X030 08 ZP F 4
17 50047 NNYL M06X1.00 08 ZP Nylock 4
18 50048 NNYL M08X1.25 08 ZP Nylon Inse 29
19 50049 NNYL M10X1.50 08 ZP Nylon Inse 4
20 50214 HHCS M06-1.00X030 08 ZP P 6
21 50219 HHCS 03/08-16X00.75 05 ZP 4
22 50237 HHCS M08-1.25X100 08 ZP P 3
23 50295 HHCS M08-1.25X15 08 ZP P 2
24 50348 HHCS M08-1.25X25 08 ZP P 6
25 50296 HHCS M06-1.00X15 08 ZP P 2
26 50030 HHCS M8-1.25 X 20 GR 8.8 ZP 15
27 50342 Carb M10-1.50X25 08 ZP Carriage 4
28 50346 FHMS M8 - 1.25 x 30 ZP 4
29 90749 Marinco Plug 2
31 83077 Control Box 1
32 91640 Electric Motor 1
33 91658 Motor Controller 1
34 91673 Pump, 10CC 1
35 91745
Contactor, 48V Contacts, 12V Coil 1
36 92563 Tank Filler W/ Strainer 1
37 92565 Internal Filter 1
38 93093 Tilt Manifold 1
39 91633 Battery Charger 1
40 91859 Inverter Option 1
41 83072 Hydraulic Manifold 1
42 92633 Rubber Door Bumper 3
43 92634 Spring Nut M8 - 1.25X20-25 6
