Page 286 Speed Level Series - Service & Parts Manual

January 2019Section 16 - Base

Item Part Number Description Qty.

1 16213 Power Module Weldment REF

2 16247 Guard, Engine Module 1

3 25429 Pad 2

4 40620 Spacer, Insulator 2

5 14896 Slide Block, Door 4

6 14826 Bracket, Cross Support 1

7 50028 Screw, M6 x 20 11

8 50068 Washer, M6 Fender 13

9 50047 Nut, M6 Nylock 12

10 HDW5724 Screw, 5/16 - 18 x 3/4 Inch, GR5 4

11 9370 Level Gauge 1

12 HDW9200 Plug, 1/4 NPT 1

13 6156 Filter Cartridge 1

14 50664 Elbow, MP-MJ90-4-4 2

15 50648 Fitting, MJ-MP-16-20 1

16 6714 Filter Head 1

17 HDW9268 Elbow, 90º 1/4 NPT - 3/4 JIC 1

18 HDW8482 Bolt, 32 × 1.57 6

19 9367 Filler/Strainer 1

20 50893 Tee, MJ-FJX-MJT-6 1

21 50649 Elbow 90, MJ-FJX90-16-16 1

22 50061 Washer, 5/16 Flat 4

23 50920 Fitting, MJ-MP90-6-4 1

REF - Reference
