Page 294 Speed Level Series - Service & Parts Manual

January 2019Section 16 - Base

Item Part Number Description Qty.

1 16213 Power Module Weldment REF

2 16211 Engine Mount, Dual Fuel 2

3 16210 Spacer 2

4 91131 Radiator Bracket Kit 1

5 91127 Coolant Overflow Tank 1

6 50028 Screw, M6 x 20 2

7 50047 Nut, M6 Nylock 2

8 6458 Hose 3 ft.

9 16295 Air Intake Weldment 1

10 HDW5723 Air Intake Weldment 2

11 HDW8267 Nut, 1/4 - 20 4

12 7736 Insulator, Rubber 8

13 40620 Spacer - Isolator 4

14 HDW8567 Washer, Flat, 3/8 4

15 HDW8279 Bolt, 3/8 - 16 x 2 1/2 GR8 4

16 HDW8268 Nut, 3/8 - 16 4

17 HDW91234 Screw, M10-1.25 x 25 8.8 12

18 50130 Washer, 1/4 Flat 2

19 90480 Washer, 3/8 x 1-1/2 Fender 4

REF - Reference
