Page 298 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
Additional attaching engine parts found earlier in this section
-- 84036 Engine Subassembly, Diesel --
1 91429 Engine Kit, D1105 1
2 91113 Radiator Kit 1
-- 9831 Radiator --
3 19405 Muffler Kit 1
-- 92164 Gasket, Exhaust (Not Shown) --
4 19458 Bracket Exhaust Mount 1
5 92533 Clamp 1-1/2” 1
6 91776 Tail Pipe 1
10 91175 Oil Pressure Switch 1
11 HDW91187 Fitting, 1/8 NPT, M–F 1
12 8665 Oil Filter 1
13 91116 Fuel Filter Assembly 1
-- 91123 Fuel Filter Element --
14 6458 Hose, Fuel, 5/16 8 ft.
15 91199 Hose, Fuel, 3/16 6 ft.
16 91114 Valve, Check 1
17 7788 Hose Clamp 5
18 8413 Starter Incl
19 90227 Alternator Incl
20 91124 Fuel Solenoid Incl
21 9832 Glow Plugs Incl
22 91112 KTR Housing Kit, D905 1
22a 91572 Coupler, Outer --
23 91130 Hub 1
24 91630 Ring Gear 1
25 91160 Hydraulic Pump 1
26 HDW6433 Screw, 3/8-16 × 1 2
27 7545 Hose Clamp 5
28 91111 Air Cleaner kit 1
-- 8667 Air Filter Element --
29 16720 Tube, Intake Extension 1
30 946640 Screw 2
31
91799 Breather Cap 1
32 16721 Bracket 1
33 16207 Bracket, Solenoid 1
34 91375 Relay 2
35 91589 Solenoid, Throttle 1
36 HDW91231 Jamnut, ¼–28 1
37 91117 Yoke 1
38 91588 Washer, ¼” Rubber 1
39 16347 Throttle Link 2
40 HDW5217 Washer, Flat, 5/16 1
41 HDW91590 Clevis Pin, 5/16 × 1 1
42 HDW5290 Cotter Pin, 1/8” × 1 1
43 50028 Screw, M6 x 20 4
44 50047 Nut, M6 Nylock 4
45 HDW5217 Flat Washer 2
Incl - Included with Assembly
