Page 300 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty. Item Part Number Description Qty
Additional attaching engine parts found earlier in this section Additional attaching engine parts found earlier in this section
-- 91035 Engine Subassembly, Dual Fuel -- 43 HDW91231 Jamnut, ¼–28 2
1 91125 Engine, Kubota DF752 1 44 50028 Screw, M6 x 20 6
2 8472 Radiator 1 45 50047 Nut, M6 Nylock 6
3 90227 Alternator, 40 AMP 1 46 91375 Relay, Throttle 1
4 8365 Starter 1 47 91375 Choke Bracket 1
5 91175 Oil Pressure Switch 1 48 9502 Choke Solenoid 1
6 HDW91187 Fitting, 1/8 NPT, M-F 1 49 9498 Choke Linkage 1
7 8516 Oil Filter 1 50 HDW91283 Screw, M6–1.0 × 25 1
8 91115 Muffler 1 51 20204 Spacer 1
-- 92164 Gasket, Exhaust (Not Shown) -- 52 9252 Throttle Linkage 1
9 91776 Tail Pipe 1 53 92944 Solenoid Gas Shutoff 1
10 92533 Clamp 1-1/2| 1 54 92945 Solenoid Propane Shutoff 1
11 -- -- -- 55 92944 Wire Assembly, Gas Shutoff Solenoid 1
12 -- -- -- 56 91046 Manifold Exhaust 1
13 93632 Air Cleaner Assembly 1 57 91559 Gasket Muffler Flange 1
14 91136 Air Filter Element 1
15 91188 Intake Hose 1
16 91340 Hose, 2.00” I.D. Flex 1
17 7545 Hose Clamp 2
18 91799 Breather Cap 1
19 91133 Carburetor Flange 1
20 91617 Carburetor Assembly 1
21 91130 Hub 1
22 91129 KTR Housing Kit, DF752 1
22a 91573 Coupler, Outer --
23 91160 Hydraulic Pump 1
24 HDW6433 Screw, 3/8-16 × 1” 2
25 91765 Ring Gear 1
26 91766 Flywheel 1
27 21020 Bracket, Components 1
28 91177 Fuel Pump 1
29 6458 Hose, Fuel, 5/16 As Req
30 7788 Hose Clamp, 5/16 5
31 8514 Fuel Filter 1
32 50015 Screw, M8 x 50 2
33 50048 Nut, M8 Nylock 2
34 7406 Hose Assembly, LP 1
35 HDW6894 Elbow, 90° Brass 1
36 91132 Valve, Lockoff 1
37 91197 LP Hose, ½” 10 in
38 91198 Radiator Hose, 3/8” 60 in
39 91232 Hose Clamp, #8 6
40 9833 LPG Regulator 1
41 91119 Solenoid, Throttle 1
42 HDW9247 Screw, Cap Socket Head, ¼–28 × 1.0” 1
As Req - As Required
To Next Page
