Page 306 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 92145 Harness, Main, Lower Control Box To Valve Manifold And Modules 1
2 92134 Harness, Main Harness To Level Manifold 1
3 92135 Harness, Main Harness To Down Valve, Axle Cylinders, Wheel Bypass 1
4 -- -- --
5 92137 Harness, Communication, Main Harness To Axle CAN-Tilt 1
6 92138 Harness, Communication, Axle CAN-Tilt Connection Adapter 1
7 92139 Harness, Communication, Axle CAN-Tilt To Boom Pivot CAN-Tilt 1
8 92140 Harness, Communication, Boom Pivot Angle CAN-Tilt Adapter 1
9 92141 Harness, Communication, Boom Pivot Angle CAN-Tilt To Platform Bottom 1
10
91780
Harness, Communication, Platform Bottom To Upper Control Box, Removable
Control Box
1
92195
Harness, Communication, Platform Bottom To Upper Control Box, Fixed Control
Box
1
11 9441
Cable, Power to Platform, 3084 (Not Shown -- Connects Plug On Module Base To
Plug At Platform)
55 ft.
Cable, Power to Platform, 2684 (Not Shown -- Connects Plug On Module Base To
Plug At Platform)
50 ft.
12 -- -- --
13 92143 Harness, Inside Upper Control Box Base -- Removable Control Box Only 1
14 92146 Harness, Lower Control Box Interior 1
15 92193 Harness, Matrix Module To Joystick 1
16 92150 Cable, Master Disconnect To Fuse 1
17 92151 Cable, Fuse To Solenoid 1
18 92151 Cable, Solenoid To Motor Controller B+ 1
19 92152 Cable, Red, Motor Controller B+ To Motor B+ 1
20 92153 Cable, Black, Motor Controller M To Motor B- 1
21 92148 Cable, Battery+ To Master Disconnect 1
22 92149 Cable, Battery- To Motor Controller B- 1
23 6208 Cable, Battery Connection 7
24 92147 Harness, Emergency Down 1
To Next Page
