Page 308 Speed Level Series - Service & Parts Manual
January 2019Section 16 - Base
Item Part Number Description Qty.
1 92133 Harness, Main, Lower Control Box To Valve Manifold And Modules 1
2 92134 Harness, Main Harness To Level Manifold 1
3 92135 Harness, Main Harness To Down Valve, Axle Cylinders, Wheel Bypass 1
4
92136 Dual Fuel - Harness, Engine, Main Harness To Engine 1
92222 Diesel - Harness, Engine, Main Harness To Engine 1
5 92137 Harness, Communication, Main Harness To Axle CAN-Tilt 1
6 92138 Harness, Communication, Axle CAN-Tilt Connection Adapter 1
7 92139 Harness, Communication, Axle CAN-Tilt To Boom Pivot CAN-Tilt 1
8 92140 Harness, Communication, Boom Pivot Angle CAN-Tilt Adapter 1
9 92141 Harness, Communication, Boom Pivot Angle CAN-Tilt To Platform Bottom 1
10
91780
Harness, Communication, Platform Bottom To Upper Control Box, Removable
Control Box
1
92196 Harness, Communication, Platform Bottom To Upper Control Box, Fixed Control Box 1
11 9441
Cable, Power To Platform, 3084 (Not Shown -- Connects Plug On Module Base To
Plug At Platform)
55
Cable, Power To Platform, 2684 (Not Shown -- Connects Plug On Module Base To
Plug At Platform)
50
12 92142 Harness, 12V Power Supply To Lower Control Box 1
13 92143 Harness, Inside Upper Control Box Base -- Removable Control Box Only 1
14 92144 Harness, Lower Control Box Interior 1
15 92193 Harness, Matrix Module To Joystick 1
16 92154 Cable, Battery+ To Master Disconnect 1
17 92155 Cable, Master Disconnect To Engine Starter 1
18 92156 Cable, Battery- To Engine 1
