Mec Speed Level Series User Manual

Page 311 Speed Level Series - Service & Parts Manual
January 2019Section 17 - Decals, ANSI Models
Decals, ES Models, ANSI Specification - Part 2
ART_3125
DecalsSigma Level
11026730
HYDRAULIC OIL
6873
90732
DO NOT POWERWASH OR
SPRAY ELECTRONIC
COMPONENTS OR
CONNECTORS.
MOISTURE MAY CAUSE
DAMAGE AND/OR
ERRATIC OPERATION
WARNING
8502
INFLATE TO TIRE
MANUFACTURER'S MAX.
SPECIFICATIONS
SERVICE MANUAL
OR SEE
ANSI Speed Level™ ES Models: Sheet 2 of 4
WARNING
90725
REPLACE TIRES WITH MANUFACTURER’S
EQUIPMENT ONLY.
FAILURE TO USE MANUFACTURER’S
TIRES MAY CAUSE MACHINE INSTABILITY.
REFER TO SERVICE AND PARTS MANUAL
FOR REPLACEMENT PART NUMBER.
39
WARNING
91774
EACH REPLACEMENT BATTERY MUST WEIGH
A MINIMUM OF 111 POUNDS / 50.3 kg
FAILURE TO MEET MINIMUM WEIGHT
REQUIREMENT MAY CAUSE MACHINE
INSTABILITY.
91864
PLATFORM
BASE
OFF
PUSH FOR EMERGENCY
STOP
TWIST TO RESET
RAISE
LOWER
15 AMP
BREAKER
EMERGENCY
LOWERING
91848
1500 LBs (680kg)
PLATFORM CAPACITY
MEC AERIAL PLATFORM SALES CORP.
MFG. DATE MODEL NUMBER SERIAL NUMBER MODELYEAR
MAX. PLATFORM CAPACITY INCLUDING PERSONS
MAX. MANUAL FORCE
ELECTRICALVOLTAGE
MAX. GROUND
PRESSURE PER WHEEL
MAX. LOAD
PERWHEEL
MAX. HYDRAULIC
SYSTEM
PRESSURE
MACHINEWEIGHT
MAX.WIND SPEEDMAX. PLATFORM HEIGHT
THIS MACHINE HAS BEEN CONSTRUCTED IN ACCORDANCE WITH SECTION 4 OF ANSI A92.6-2006 COVERED BY US PAT. #5,476,050 & CANADIAN PAT. #2,115,870
MAX. DRIVE HEIGHT
XX/XX XXXXXX XXXXXXXXX 20XX
XXX kg = X PERSONS + XXX kg EQUIPMENT
XXX LBS
XXX kg = X PERSONS + XXX kg EQUIPMENT
XXX N
XXXX LBS
XXXX kg
XXX LBS
XXX kg
XXXX PSI
XXXX bar
XX VOLTS
X.X PSI
X.X kg/cm²
X MPH
X m/s
X X FT
X.X m
X X FT
X.X m
92122
1700 LBs (770kg)
PLATFORM CAPACITY
23
24
25
26 27
28
29 30 31
33
34
36
37
38
32
22
ES MODELS - ANSI
3084
2684
