mecalac 12 MXT - Table of Stability Loads in kg; Lifting and Handling in the Longitudinal Position with Standard or Telescopic Stabilizers

28000 12MXT
M1 11
5.1 Lifting and handling in the longitudinal position
with standard or telescopic stabilizers
Working conditions:
- On wheels with the stabilizers.
- On level, compact ground.
- Equipment used without any offset.
- Front and rear chassis sections aligned.
- Without any tool (bucket, loader, etc.) with handling plate +
hook.
Stability loads and hydraulic limits according
to standard ISO 10567.
5. Table of stability loads in kg
7 m
6 m
5 m
4 m
3 m
2 m
1 m
0 m
1 m
2 m
3 m
4 m
0 m
1 m
1 m
2 m2 m 3 m
3 m 4 m
5 m
6 m
7 m
2400
1700 1300
2000
1400
3200
3200
1900
1300
1200
2000 1750
1450
2700
