mecalac 12 MXT - Safety Valves (Option)

28000 12MXT
M1 41
9.13 Safety valves (option)
F6
F5
F4
B11
M4
M3
M2
M1
M5
C1
G1
F3
B11 - Functions block (High pressure)
C1 - SX14 valve block
F3 - Dipper ram
F4 - Intermediate boom ram
F5 - Piloting unit (Low pressure)
F6 - Boom ram
G1 - Bucket ram
M1 - Boom ram valve
M2 - Load detector
M3 - Intermediate boom ram valve
M4 - Dipper ram valve
M5 - Bucket ram valve
