mecalac 12 MXT - 10 Parts List of the Hydraulic Diagram

10. Parts list of the hydraulic diagram
1-Auxiliary function
2-Dipper ram
3-Bucket ram
4-Intermediate boom ram
5-Boom ram
6-Orientation engine
7-Hydro-Sensor block
8-Braking block
9-Offset ram
10 - Tool unlock ram
11 - 1 bar valve
12 - Left manipulator
13 - Right manipulator
14 - H.P. function block
15 - Parking brake manipulator
16 - Brake / Inching foot control
17 - Accelerator foot control
18 - LP function block
19 - Safety valve
20 - Priority valve
21 - ORBITROL steering device
22 - Steering ram
23 - Steering / rotation pump
24 - 15 bar manocontact
25 - Equipment pump
26 - Check valve ARQ 0.5 bar
27 - Transfer movement pump
28 - Transfer movement engine
29 - Parking brake ram
30 - Inching valve
31 - Return filter
32 - 350 g pressurised air valve
33 - Oscillation locking ram
34 - Left stabilizer ram
35 - Stabilizer block
36 - Rotary coupling
37 - Hydraulic reservoir
38 - Service brake ram
39 - Check valve ARQ 0.5 bar
40 - Auxiliary pedal control
41 - Accelerator ram
42 - Heat engine
43 - Right stabilizer ram
44 - Oscillation locking block
45 - Service brake ram
46 - 3 bar valve
47 - Cooling system
48 - 0.5 bar valve
49 - 0.5 bar valve
50 - 6 bar valve
51 -
SX14 valve block
52 - 1.7 bar manocontact
53 - 15 bar manocontact
54 - 10 bar manocontact
55 - Accumulator 0.35 l / 15 bar
56 - Accumulator 0.35 l / 15 bar
57 - Accumulator 0.7 l / 18 bar
58 - 26 bar manocontact
59 - 1 bar valve
60 - 15 bar manocontact
61 - 120 bar manocontact
62 - Stabilizer ext. offset block
63 - Stabilizer ext. offset block
64 - Left stabilizer extension ram
65 - Right stabilizer extension ram
66 - Air conditioning block
67 - Air conditioning motor
68 - Solenoid-operated air conditioning valve
69 - Manual accelerator block
70 - Two-ways valve
28000 12MXT
M1 45
6891055
