mecalac 12 MXT - Volvo Tool-Holder (Option)

28000 12MXT
M1 43
9.15 Volvo tool-holder (option)
AB
T
P
M1
A2
D1
D2
T2
1
X
T1
O2
B11
O1
C6
C5
B11 - Functions block (High pressure)
C5 - Hydraulic turntable slewing motor
C6 - CROSS OVER block with damped valve
O1 - Tool-holder ram
O2 - Tool-holder solenoid-operated valve
