11. Installation of the electric bundles
1-Left rear light connection
2-Right rear light connection
3-Motor bundle
4-Electric collector bundle
5-Relay plate bundle
6-Cab connection
7-Solenoid-operated valves bundle
8-Left front headlight connection
9-Driver station bundle
10 - Steering column bundle
11 - Instrument panel connection
12 - Foot controls bundle
13 - Right front headlight connection
14 - Hydraulic manipulators connection (on driver station bundle)
15 - Manual accelerator bundle
16 - Air conditioning bundle
17 - Battery bundle
18 - Seat bundle (option)
