mecalac 12 MXT - Page 28

12MXT 28000
26 M1
1-Sequence valve
2-Solenoid-operated oscillation locking valve
3-Transfer movement engine
4-Transfer movement pump
5-Stabilizers solenoid-operated valve
6-Equipment pump
7-Orientation pump
8-Telescopic stabilizer selector
1
3
2
6
7
4
5
8
