mecalac 12 MXT - Page 30

12MXT 28000
28 M1
1-Rotary coupling
2-Left manipulator
3-Additional functions foot control
4-Brake / Inching foot control
5-ORBITROL steering device
6-Accelerator foot control
7-Right manipulator
8-Parking brake control lever
1
2
3
4
5
6
7
8
