12MXT 28000
62 M1
14.2.2 Starting
1- Place the machine on a solid, flat surface before
engaging high speed.
2- Accelerate the engine progressively until the machine
starts.
3- Read the engine revs by monting an inductive sensor
on the flywheel (1 fig. 1).
4- If the regime of the engine is too low, turn the screw
(1 fig. 2) clockwise in order to increase the speed of
the engine.
13 flat spanner
4 male hexagonal spanner
Inductive sensor
Manometer 0 - 600 bar
1
Operation
Speed
(rpm)
Measurement
(ref. no.)
Adjustment
(ref. no.)
Starting 1,100 (+50 -30) 1 fig. 1 1 fig. 2
Fig. 2 Transfer movement pump
Fig. 1 Heat engine
1
