mecalac 12 MXT - Page 84

12MXT 28000
82 M1
1 2
3
4
1-Flexible hose (connection from the turbine to the SX18 valve block)
2-Turbine (flow meter)
3-Connecting cable
4-Flexible hose (connection from the turbine to the SX18 valve block)
Fig. 3 TOP-TEST MX toolbox, lower foam section
