5. During measurement, you can press Change to change the start point
and the end point; if you press Change again, the system interchanges
line A and line B.
6. Roll the trackball and press Set to complete this measurement.
7. Roll the trackball and press Set again to begin a new angle
measurement. You can measure a maximum of four groups of data.
The angles formed by the two lines are displayed in measurement
result window, in units of degrees. The outcome will be displayed in
the measurement result window.
8. Press Measure to finish and exit.
Freeze the image first before histogram measurement, otherwise the
prompt “Image is not frozen, please freeze and retry!” will pop up.
1. Press Measure to activate measurement function.
2. Roll the trackball to highlight menu Histogram, and then press Set to
activate a measurement cursor on the screen.
3. Roll the trackball, press Set to anchor the start point.
4. Roll the trackball, adjust the position and size of the histogram, and
then press Set to anchor the end point.
5. During measurement, you can press Change to change the start point
and the end point.
6. Roll the trackball and press Set again to begin a new histogram
measurement. You can measure a maximum of four groups of data.
The outcome is displayed in Measured Results.
7. Press Measure to finish and exit.
