P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual
- 37 -
levels are available: 100%，144%，196%, 256%, 400%, 576%,
900%, 1600%(in area). Press Set display the zoomed image, and
then roll the trackball to move the zoomed image.
NOTE:
In real-time mode, magnification function is only available in B-mode
and 2B-mode. In frozen mode, magnification function is only
available in B-mode.
 When a body mark is added, the rotation function is automatically
activated and the rotation light is on. You can rotate this button to
adjust the scanning direction.
 When an arrow is added, the rotation function is automatically
activated and the rotation light is on. You can rotate this button to
adjust the arrow direction.
 In PW mode, after activating the PW angle adjustment function, the
rotation function is automatically activated and the rotation light is
on. You can rotate this button to adjust the arrow direction.
Footswitch
Pedaling on the footswitch is equivalent to pressing Freeze.
Table 5-2 Function Controls
5.4.5. Comment Function
The comment library is for positions and anatomical structures.
NOTE:
The entered text is in upper case by default.
To add a comment:
➢ To add a comment by using the keyboard:
1. Press Comment, and there is a cursor “І” displayed in the image area for annotating;
2. Enter text by using the keyboard;
3. Press Set to complete the comment.
➢ To add a comment by using the comment library:
1. Press Comment, and there is a cursor “І” displayed in the image area for annotating;
2. Press Change to display the comment library;
3. Highlight a comment in the comment library, and press Set to confirm the choice and
complete the comment.
