P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual
- 90 -
7.1.2. Gallbladder
1. In the abdominal measurement menu, roll the trackball to highlight Gallbladder, select GB-L,
GB-W or GB-H from the secondary menu，and then press Set.
2. Measure GB-L, GB-W or GB-H by the method of distance measurement.
Reference Section 6.6.1 Generic Measurement in B mode.
3. After the measurement, the result of gallbladder will be displayed in the measurement result
window.
7.1.3. Kidney
1. In the abdominal measurement menu, roll the trackball to highlight L Kidney/R Kidney,
select L.KID-L/L.KID-W/L.KID-H, or R.KID-L/R.KID-W/R.KID-H from the secondary
menu, and then press Set.
2. Measure KID-L, KID-W, or KID H, by the method of distance measurement.
Reference Section 6.6.1 Generic Measurement in B mode.
3. After the measurement, the result of kidney will be displayed in the measurement result
window.
7.1.4. Bladder
1. In the abdominal measurement menu, roll the trackball to highlight Bladder, select BL-L,
BL-W, or BL-H from the secondary menu, and then press Set.
2. Measure BL-L, BL-W, or BL-H, by the method of distance measurement.
Reference Section 6.6.1 Generic Measurement in B mode.
3. After the measurement, the result of bladder will be displayed in the measurement result
window.
7.2. Abdominal Report
After the abdominal examination, the system generates an abdominal worksheet.
1. Select the exam mode Abd-Small/Abd-Large.
2. In B mode, after application measurements press Abd worksheet to open Abdominal
