8 SPECIFICATIONS
8
Specifications
Specifications MOM2
Specifications are valid at fully charged batteries and an ambi-
ent temperature of +25°C, (77°F). Specifications are subject to
change without notice.
Environment
Application field For use in high-voltage substations
and industrial environments.
Temperature
Operation -20ºC to +50°C (-4°F to +122°F) *
)
Storage -40ºC to +70ºC (-40°F to +158°F)
Relative humidity %RH 5%-95%, non condensing
Pollution degree 2
Shock IEC 60068-2-27
Vibration IEC 60068-2-6
Transport ISTA 2A
Flammability class V0
*) Battery operation temperature 0ºC to +50° (32°F to
+122°F)
Battery charging temperature +10ºC to +40° (50°F to +104°F)
CE-marking
EMC 2004/108/EC
LVD 2006/95/EC
General
Battery power Five AA (HR6) 2700 mAh NiMH cells
Recharge time < 12 h
Typical recharge time at
25°C
3 h
Battery charger
Mains voltage 100 - 250 V AC, 50 / 60Hz
Power consumption 60 W
Protection Against wrong battery type, low/high
temperature.
Real time clock battery life ≥10 year s
Audible feedback Different buzzer sounds
User presets 3
Field calibration Yes
Encapsulation IP54
Dimensions (excl. binding
posts)
217 H x 92 B x 72 D mm
8.5 H x 3.6 B x 2.8 D in.
Weight 1.0 kg (2.2 lbs) instrument only
5.0 kg (11 lbs) with accessories and
carrying case
Measurement section
Minimum current guar-
antee
Selectable 50 A / 100 A
Valid at resistance ≤2mΩ
Pass / Fail Settable from 1 µΩ to 1999 mΩ
Number of measurements
on fully charged batteries
typ. 2200 at I min = 50 A and 0.1 s
typ. 800 at I min = 100 A and 0.1 s
Interference suppression Yes
Range 0 - 1000 mΩ
Range selection Auto
Resolution
0 – 999 µΩ 1 µΩ
1.0 – 9.99 mΩ 0.01 mΩ
10.0 – 99.9 mΩ 0.1 mΩ
100 – 1000 mΩ 1 mΩ
Inaccuracy
0 – 1999 µΩ ±1 % of reading ±1 digit
2 – 1000 mΩ ±2 % of reading ±1 digit
Outputs + / –
Range > 100 A DC (R < 2 mΩ)
Output voltage (max) 2.5 V DC
Generation duration Selectable: 0.1 s, 0.6 s, 3 s
Recovery time at I min set to 100
A and load 100 μΩ
Generation time Max Typ
0.1 s 10 s 8 s
0.6 s 20 s 16 s
3 s 130 s 100 s
Inputs
SENSE + / –
Connector 4 mm banana jack
Voltage ±3 V DC
Trigger input Threshold 8 V DC
DC IN 12 – 24 V DC, 2 A max
Logger
Logger, Data Label. Timestamp, I max, I min, I Lim-
it, Resistance, Meas.time, P/F limit
Labeling schemes Circuit breaker oriented or running
numbers
Capacity 190 measurements
Wireless communication
Headset Bluetooth
PC communication Bluetooth
