DET2/3
21
Continuity Test
Manual mode Continuous graphical mode
6
Press
Press
See Data management (page 33).
Note: Press Save at any time to save the current reading.
Null test leads
Note: Test must be running to be able to Null the test leads.
The Null function only works when the measured resistance is less than 10 Ω.
1. Put the two test lead tips firmly together.
2. Press .
When the test result shows, press again to activate / de-activate the Null process:
Null active: Result is minus the test lead resistance.
The Null function is active while results are continuously updated or when results update is stopped.
Null de-active: Result includes test lead resistance.
If the measured resistance is below zero, while Null is active, the result will show that it is too low to measure
(the instrument will not show negative resistance values).
OR
