DET2/3

Overview

User interface

No. Description No. Description

1 External power / battery charge socket 6 Function switch (Controls (page 7))

2 Display 7 Navigation control panel (page 8)

3 USB: 1x Type A / 1x Type B 8 Mode switch (Controls (page 7))

4 Soft keys (page 9) 9 Save (Test Result Management (page 36))

5 Terminals (page 8) 10 External power LED (Power on / Charge (page 10))
