Megger DET2/3 - Test Methods: 61.8% Rule; 61.8% Rule (FoP) Overview; 61.8% Rule: Four Terminal Set-up; 61.8% Rule: Three Terminal Set-up

DET2/3
29
Test methods and set-up
61.8% Rule (FoP)
61.8% Four terminal test lead set-up
G
F
V
I
C1 E
E/X
CAT IV 300V CAT IV 300V CAT IV 300V CAT IV 300V
Y
V
P1 ES P2 S C2 H
61.8% of EC 38.2% of EC
Electrode under test Potential spike Current spike
P1
P2
C2
61.8% Three terminal test lead set-up
G
F
V
I
C1 E
E/X
CAT IV 300V CAT IV 300V CAT IV 300V CAT IV 300V
Y
V
P1 ES P2 S C2 H
100%
P1
P2 C2
