DET2/3

Accessories

Warning: Use only Megger approved test leads and accessories with this instrument.

Item Part Number

Cable reel kit ETK30 1010-176

Cable reel kit ETK50 1010-177

Cable reel kit ETK100 1010-178

Cable reel kit ETK50C 1010-179

Cable reel kit ETK100C 1010-180

Clamp MCC1010 1010-516

Clamp MVC1010 1010-518

12 V dc power lead 1004-183

Terminal adapter, detachable retro-ﬁt for C1, P1, P2, C2 connectors 6220-803

Power supply 18 V >3.5 A 1010-793
