DET2/3
27
Test methods and set-up
Table 1: Values of D
P
/ D
C
for various values of µ
µ D
P
/ D
C
µ D
P
/ D
C
µ D
P
/ D
C
0.40 0.643 0.80 0.580 1.20 0.494
0.41 0.642 0.81 0.579 1.21 0.491
0.42 0.640 0.82 0.577 1.22 0.488
0.43 0.639 0.83 0.575 1.23 0.486
0.44 0.637 0.84 0.573 1.24 0.483
0.45 0.636 0.85 0.571 1.25 0.480
0.46 0.635 0.86 0.569 1.26 0.477
0.47 0.633 0.87 0.567 1.27 0.474
0.48 0.632 0.88 0.566 1.28 0.471
0.49 0.630 0.89 0.564 1.29 0.468
0.50 0.629 0.90 0.562 1.30 0.465
0.51 0.627 0.91 0.560 1.31 0.462
0.52 0.626 0.92 0.558 1.32 0.458
0.53 0.624 0.93 0.556 1.33 0.455
0.54 0.623 0.94 0.554 1.34 0.452
0.55 0.621 0.95 0.552 1.35 0.448
0.56 0.620 0.96 0.550 1.36 0.445
0.57 0.618 0.97 0.548 1.37 0.441
0.58 0.617 0.98 0.546 1.38 0.438
0.59 0.615 0.99 0.544 1.39 0.434
0.60 0.614 1.00 0.542 1.40 0.431
0.61 0.612 1.01 0.539 1.41 0.427
0.62 0.610 1.02 0.537 1.42 0.423
0.63 0.609 1.03 0.535 1.43 0.418
0.64 0.607 1.04 0.533 1.44 0.414
0.65 0.606 1.05 0.531 1.45 0.410
0.66 0.604 1.06 0.528 1.46 0.406
0.67 0.602 1.07 0.526 1.47 0.401
0.68 0.601 1.08 0.524 1.48 0.397
0.69 0.599 1.09 0.522 1.49 0.393
0.70 0.597 1.10 0.519 1.50 0.389
0.71 0.596 1.11 0.517 1.51 0.384
0.72 0.594 1.12 0.514 1.52 0.379
0.73 0.592 1.13 0.512 1.53 0.374
0.74 0.591 1.14 0.509 1.54 0.369
0.75 0.589 1.15 0.507 1.55 0.364
0.76 0.587 1.16 0.504 1.56 0.358
0.77 0.585 1.17 0.502 1.57 0.352
0.78 0.584 1.18 0.499 1.58 0.347
0.79 0.582 1.19 0.497 1.59 0.341
