E-SC1B 1
Standard Class 1
Earthed Equipment
200mA Continuity Test
Visual Inspection
Earth Continuity
Insulation test at 500V
Operation test (230V)
Differential Earth Leakage (230V)
≤0.1Ω
≥1MΩ
≤3000VA
≤3.5mA
5s
5s
5s
5s
PAT410
PAT450
E-SC1B-RCD 1
Standard Class 1
Earthed Equipment with
RCD Protection
200mA Continuity Test
Visual Inspection
RCD 30mA test
Earth Continuity
Operation test (230V)
Differential Earth Leakage (230V)
≤0.1Ω
≤3000VA
≤3.5mA
5s
5s
5s
PAT410
PAT450
E-SC2 2
Typical Class 2
Double Insulated
Visual Inspection
Insulation test at 500V
Operation test (230V)
Touch Current (230V)
≥2MΩ
≤3000VA
≤0.25mA
5s
5s
5s
PAT410
PAT450
E-FAN 2
Desk Fan
Double Insulated
Visual Inspection
Insulation test at 500V
Operation test (230V)
Touch Current (230V)
≥2MΩ
≤200VA
≤0.25mA
5s
5s
5s
PAT410
PAT450
E-PC 1
Personal Computer
IT Equipment
Visual Inspection
Earth Continuity
Operation test (230V)
Differential Earth Leakage (230V)
≤0.1Ω
≤500VA
≤3.5mA
5s
5s
5s
PAT410
PAT450
E-DRY 2
Hairdryers
Double Insulated
Visual Inspection
Insulation test at 500V
Operation test (230V)
Touch Current (230V)
≥2MΩ
≤1500VA
≤0.25mA
5s
5s
5s
PAT410
PAT450
E-KET 1
Kettles
Earthed
Visual Inspection
Earth Bond at 25A
Insulation test at 500V
Operation test (230V)
Differential Earth Leakage (230V)
≤0.1Ω
≥1MΩ
≤2500VA
≤3.5mA
5s
5s
5s
5s PAT450
E-KETB 1
Kettles
Earthed
200mA Continuity Test
Visual Inspection
Earth Continuity
Insulation test at 500V
Operation test (230V)
Differential Earth Leakage (230V)
≤0.1Ω
≥1MΩ
≤2500VA
≤3.5mA
5s
5s
5s
5s
PAT410
PAT450
E-EL1 EXT
230V Extension Leads
3 Core
Visual Inspection
Polarity
Earth Bond at 25A
Insulation test at 500V
≤0.1Ω
≥1MΩ
5s
5s PAT450
E-EL1B EXT
230V Extension Leads
3 Core
200mA Continuity Test
Visual Inspection
Polarity
Earth Continuity
Insulation test at 500V
≤0.1Ω
≥1MΩ
5s
5s
PAT410
PAT450
E-EL2 EXT
230V Extension Leads
2 Core
Visual Inspection
Polarity
Insulation test at 500V ≥2MΩ 5s
PAT410
PAT450
