www.megger.comPAT400 Series
89
Fuse test
■ ■ ■
Test voltage: 3.3 V
■ ■ ■
Warning: Audible beep if fuse is OK
■ ■ ■
Environmental
■ ■ ■
Weight - Instrument (with packaging) 2.7kg (3.2kg)
■
Weight - Instrument (with packaging) 4.4kg (4.9kg)
■
Weight - Instrument (with packaging) 5.0kg (5.5kg)
■
Dimensions (mm) - Instrument 120(H-int) x 145(H-UK) x 255(W) x 320(L)
■
Dimensions (mm) - Instrument 155(H-int) x 180(H-UK) x 255(W) x 320(L)
■ ■
Dimensions (mm) - Packaging 210(H) x 280(W) x 390(L)
■ ■ ■
Operating temperature: -10°C to +50°C
■ ■ ■
Storage temperature: -20°C to +60°C
■ ■ ■
Humidity: 90%RH @ -10°C +30°C
75%RH @ +30°C to +50°C
■ ■ ■
■ ■ ■
Maximum altitude: 2,000m
■ ■ ■
Dust and water ingress protection: IP40
■ ■ ■
Design Standards
■ ■ ■
Safety: IEC 61010-1: CAT II 300V
■ ■ ■
EMC IEC 61326-1: 2006
IEC 61326-2-2: 2005.
■ ■ ■
■ ■ ■
