ACCEPTANCE TEST
When the product is successfully mounted and connected to the machine, you will need to
perform coin/token acceptance test. This test will confirm that the validator has been set up
correctly.
After Installing the Validator
• Press and release the reject button on the machine.
• Confirm that the lid on the front of the validator closes fully when the reject button is
released. If it does not close fully, the validator cannot function properly (i.e.
coin/token may be rejected).
• Test that power to the validator is on by checking that the green LED is fully lit.
No power on product
Unit working OK
Unit faulty
Testing for Acceptance
• Insert into the machine a selection of coins/tokens to check that they are accepted by
the validator. The green LED will flash off once to indicate a valid accepted
coin/token. If the coin/token has been rejected refer to the table below.
Coin Accepted by Unit
Coin Unrecognised by Unit
Coin Inhibited by Unit
Coin Inhibited by Host Machine
Example:
LED Key: =
R
☺
OFF
G
G
R
R
R
2 x Flashes
3 x Flashes
4 x Flashes
1 x Flashes
G
G
G
G
G
Green ON
R
Red Flashing
G
Green Flashing
OFF
G
1 x Flashes
G
Green LED flashes once then LED turns to solid Green ON
