CashFlow
952X / 952Xe / 9510 User Guide
MEI., 2005 Page 27 Rev: G2
CF952Xe
Most of the functionality of the DIL switches on the CF952Xe are identical to the CF952X,
with the exception of the assignment and behavior of switches 1 and 2. On these models,
Serial Mode is enabled by setting SW2 ON. While SW2 is ON, SW1 operates as a serial
mode select switch. When SW1 is OFF, the serial mode selected is HII. When SW1 is ON,
the serial mode selected is ccTalk.
Do I Need to Switch the Power Off and On?
Switch up = ON
Switch down = OFF
Description Turn Power Off and On
1
Alarm Enable/ ccTalk
Not Required / Yes
2
HII Serial Mode
CcTalk Serial Mode
Yes (sw 1 OFF)
Yes (sw 1 ON)
3
Enable Coin Yes
4
Inhibit Coin Yes
5
Teach Token 1 Yes
6
Teach Token 2 Yes
7
Primary Route Teach Yes
8
Secondary Route Teach Yes
CF9510
Again, the assigment of the switches is slightly different on the CF9510. While switches 3
through 6 remain the same as in the CF952X/CF952Xe, switches 1 and 2 select the output
mode configuration. Switches 7 and 8 put the unit into Parallel Output teach mode and
Multi-pulse teach mode, respectively.
Do I Need to Switch the Power Off and On?
Switch up = ON
Switch down = OFF
Description Turn Power Off and On
1
Parallel/BCO mode Yes
2
Extended Features Yes
3
Enable Coin Yes
4
Inhibit Coin Yes
5
Teach Token 1 Yes
6
Teach Token 2 Yes
7
Primary Route Teach Yes
8
Secondary Route Teach Yes
