4 Description of the device
16
A spring clip is located on the rear panel of the sterilization chamber to fix the mount. When using a “Plus”
mount, slide the mount into the sterilization chamber to its fullest extent, until the mount snaps into the
spring clip.
Colour-touch display
The operating panel consists of a colour 5 inch touch display.
Symbols in the status bar Meaning
Program/tests Indicates whether a program/test is running
Immediate output Indicates whether immediate output is activated/deactivated
Additional drying Indicates whether additional drying is activated/deactivated
Graphic logs Indicates whether the graphic log recording is activated/deactivated
Energy-saving
mode
Indicates whether the steam sterilizer is currently in energy-saving
mode
Service area Indicates whether a service technician is logged-in to the service area
CF card status Indicates whether a CF card has been inserted and whether a reading
or writing action is in process.
