14 Technical data
77
14 Technical data
Device type Vacuklav 41 B+ Evolution Vacuklav 43 B+ Evolution
Device dimensions (H x W x D) 56.5 x 47 x 57.5 cm 56.5 x 47 x 69 cm
Chamber diameter/depth Ø 25 cm | 35 cm Ø 25 cm | 45 cm
Chamber volume 18.4 litres 23.8 litres
Empty weight 60 kg 69 kg
Operating weight 81 kg 91 kg
Electricity supply 220-240 V, 50/60 Hz, 3400 W
Building fuses 16 A, FI protection 30 mA
Waste heat (with maximum
load)
1.7 kWh
Noise emission 64 dB(A)
Ambient temperature 5-40 °C (ideal range 16-26 °C)
Relative humidity max. 80% at 31 °C, decreases in a linear fashion up to max. 50%
relative humidity at 40 °C
Max. height 4000 m
Length of the power cable 2 m
Degree of protection (following
IEC 60529)
IP20
CE marking CE 0197, CE 0035
Feed water connection
Water quality DIN EN 13060, Appendix C
Min. flow pressure 1.5 bars at 3 l/min
Min. static water pressure 2 bar
Max. static water pressure 10 bar
Max. water consumption 0.74 L 0.83 L
Waste water connection
Max. through-flow volume 1.5 L 1.5 L
Max. water temperature 98 °C 98 °C
