Note: Not all the screws are the same length. Ensure that you use the same screws for the origi-
nal position later in this procedure.
13. Remove the left side cover from the machine.
14. Using a small oiler bottle, place twenty ve (25) drops of sewing machine oil into the oiling port as
shown in the image.
•
Note: You may need to add a few drops and wait before adding more to prevent the oiling port
from overowing.
15. Position the left side cover in its original location on the machine as shown in the image.
16. Loosely install one (1) of the rear (shorter) mounting screws to hold the cover in place.
17. Install the other two (2) mounting screws. The longer of the screws secures the front. The shorter
of the screws secures the rear.
18. Carefully tighten all three (3) screws only enough to secure the cover in place. Over-tightening of
the screws may result in cosmetic damage to or cracking of the cover.
19. Color change to move the needle case to needle #1.
20. Using a 3mm Allen wrench, loosen and remove the four (4) screws securing the right side cover as
shown in the image.
