Meler Macro Series User Manual

INTRODUCTION
2-5
MA-5052-ENG MACRO SERIES MELTER MANUAL
1. Front control card.
2. Access door to the electronic section and connections.
3. Pumping control card.
4. Main power switch.
5. Electrical main supply input.
6. Unit transport wheels.
7. Tank access cover.
8. Hose output distributor (up to 2 hydraulic connections per motor-single
pump or 4 per motor-double pump assembly). Right side or rear placed.
9. Hose-applicator electrical connections. Right side or rear placed.
10. By-pass valve pressure regulator with pressure gauge (optional system).
11. Mechanical by-pass valve pressure control.
12. Pneumatic by-pass valve pressure control (optional system).
13. Pump filter.
14. Purge valve.
15. Tank-distributor shut off valve.

Meler Macro Series Specifications

General

Brand	Meler
Model	Macro Series
Category	Industrial Electrical
Language	English
