MELTER OPERATION MA-5052-ENG MACRO SERIES MELTER MANUAL
Alarm displays
Macro series melter equipment tell the user when a malfunction has occurred
in the unit, sending warning messages that may be seen on the control panel
display.
When an alarm appears, the control unit takes a series of steps to protect the
unit. Simply correct that malfunction and the control unit will reactivate the
equipment functions.
Standby function does not generate any alarm.
If a temperature sensor is broken, the system heats all the elements except
the one where the failure is located.
In case of overheating the system cuts off inmediately the damaged element.
After three minutes if the failure continues all the system will be shut down.
After repairing the failure the system starts heating normally.
Code Source Actions
Heating Pump Main machine signal
Err 0 tank broken sensor only tank off off off
Err 1 distributor1 broken sensor only distributor1 off off off
Err 2 distributor2 broken sensor only distributor2 off off off
Err 3 distributor3 broken sensor only distributor3 off off off
Err 4 distributor4 broken sensor only distributor4 off off off
Err 5 hose1 broken sensor only hose1 off off off
Err 6 applicator1 broken sensor only applicator1 off off off
Err 7 hose2 broken sensor only hose2 off off off
Err 8 applicator2 broken sensor only applicator2 off off off
Err 9 hose3 broken sensor only hose3 off off off
Err 10 applicator3 broken sensor only applicator3 off off off
Err 11 hose4 broken sensor only hose4 off off off
Err 12 applicator4 broken sensor only applicator4 off off off
Err 13 premelter broken sensor only premelter off off off
Err 100 tank overheating all components off off off
Err 101 distributor1 overheating all components off off off
Err 102 distributor2 overheating all components off off off
Err 103 distributor3 overheating all components off off off
Err 104 distributor4 overheating all components off off off
Err 105 hose1 overheating all components off off off
Err 106 applicator1 overheating all components off off off
Err 107 hose2 overheating all components off off off
Err 108 applicator2 overheating all components off off off
Err 109 hose3 overheating all components off off off
Err 110 applicator3 overheating all components off off off
Err 111 hose4 overheating all components off off off
Err 112 applicator4 overheating all components off off off
Err 113 premelter overheating all components off off off
