4-7
MELTER OPERATION MA-5052-ENG MACRO SERIES MELTER MANUAL
The general process for adjusting the temperatures of each components is
described below.
1. Select the component whose value you wish to modify using the left-
right arrow. The tank and the distributor have the same set point value.
The corresponding LED will blink rapidly.
2. Select the desired set point temperature value with the up-down arrow.
Below 40°C the set point value displays ‘OFF’ canceling the heating of
that element.
3. After ten seconds, the LED will stop blinking and the display will show
the tank’s set point temperature value by default, saving the modified
data.
This simple procedure should be repeated for each of the components whose
set point temperature value you wish to modify.
Programming the applicator parameters
1. Simultaneously press the buttons with the clock symbol and the down
arrow to enter the special menu.
The choice of temperature display units (°C or °F) will appear on the
display.
2. Select the desired value using the up-down arrow.
3. Use the right arrow to move to the next display where the overheating
symbol appears.
4. Select the desired value (between 10 and 25) using the up-down arrow.
The value shown corresponds to the increase in real temperature
allowed over the set point temperature without activating the alarm
message.
5. Use the right arrow to go to the next display where the standby function
symbol appears.
6. Use the up-down arrow to select the desired value (between 25 and 55).
offoff
40ºC40ºC
160160160160
--
--
--
10 10
--
--
--
55 55
ºCºC
