Meler Macro Series User Manual

FOCKE MELER GLUING SOLUTIONS
9-6
SPARE PARTS LIST
E. ELECTRICAL CABINET
Nº Ref. Description
1 150028140 PG 21 cable gland
2 10140040
PG 13.5 cable gland
3 150113660 Control board
4 150117100 Pumping control card
5 150113680 Power control board 6 outputs
5 150113670 Power control board 2 outputs
6 150024710 Sensor board Pt100/Ni120
7 150028150 Control to power board ribbon cable assembly
8 150024740 Control to sensor board cable assembly
9 150091610 2-contact 24V AC relay
10 150091370 Motor inverter G110 0.55kW to geared motor up to 0.375kW
10 150091580 Motor inverter G110 1.1kW to geared motor up to 0,75kW
10 150091590 Motor inverter G110 1.5kW to geared motor 1.1kW
11
150126410
Motor inverter V20 0.55kW to geared motor up to 0.375kW
11
150127100
Motor inverter V20 1.1kW to geared motor up to 0,75kW
11
150127140
Motor inverter V20 1.5kW to geared motor 1.1kW
12 150091600 DC power supply 24V 2,2A
13 150028160 Solid state relay 30A
14 150024090 Circuit-breaker 10A 1-pole
15 10000440 Circuit breaker, 16A 3-pole
16 150110700 Circuit breaker, 32A 3-pole
16 150021010 Circuit breaker, 16A 2-pole (50)
17 150024440 Circuit breaker, 63A 4-pole (120)
17 150118130 Main switch 40A 4-pole (50)
17.1 150118140 Main switch 63A 4-pole (120)
18 150118150 Main switch handle
19 150118360 Contact 45A 4-pole 24V DC
20 150112570 Fuse 16A 10x38 ultra fast
21 150112410 Fuse 6,3A 5x20 ultra fast
22 150112560 Fuse 6.3A 6x32 ultra fast
23 16010003 8 pin female connector (base housing)
24 150020720 12 pin female connector (base housing)
- 150117130 Programmable relay LOGO
