[=] to accept the displayed function from the
above list. From the SEQUENCE MODES
screen each of the available operations are
explained below beginning with CREATE.
Create/Delete Sequence
To program (create) a new sequence:
Press [=] with CREATE/DELETE SE-
QUENCE on the bottom line. The display will
change to:
[=]
SELECT SEQUENCE TO CREATE/DELETE:
ENTER 1 - 64 THEN PRESS =:2
The bottom line will show either a question
mark (?) or the sequence number which was
used last. To select a sequence to create (or
delete) scroll through the existing sequences
by pressing [+] or [–]. Either enter any unused
number [n], or if the displayed number is to
be deleted or replaced press [=].
[=]
SEQUENCE 2 CURRENTLY EXISTS,
PRESS = TO WRITE OVER, CE TO QUIT
The above screen appears only if an existing
sequence already bears the same number.
Otherwise, the display will offer a choice from
threeavailablesequenceprogramming
modes: MANUAL, AUTOMATIC UP-
SCALE/DOWNSCALE, or AUTOMATIC SIN-
GLE DIRECTION.
[=]
SELECT CREATE MODE: (USE +,-,=,CE)
MANUAL
[+]
SELECT CREATE MODE: (USE +,-,=,CE)
AUTOMATIC UPSCALE/DOWNSCALE
[+]
SELECT CREATE MODE: (USE +,-,=,CE)
AUTOMATIC SINGLE DIRECTION
Step through the choices with [+] or [–], then
press [=] for the desired mode.
Create: Manual
A blank Programming Log is included in the Ap-
pendix as an aid to programming sequences. The
user can photo-copy the log, script the desired
steps on it, then follow the log to program the PCS
400.
To create a sequence in manual mode press [=]
with MANUAL displayed on the bottom line. The
step number will begin at 1, and will increment
automatically. Otherwise, each parameter of every
step is entered from the keypad by the user. The
first parameter of each step sets the functional
mode, STANDBY, MEASURE, CONTROL, VENT or
LOOP, except LOOP is not available for step 1:
[=]
SEQUENCE:1 STEP:1 (USE +,-,=,CE)
SELECT MODE: STANDBY
[+]
SEQUENCE:1 STEP:1 (USE +,-,=,CE)
SELECT MODE: MEASURE
[+]
SEQUENCE:1 STEP:1 (USE +,-,=,CE)
SELECT MODE: CONTROL
[+]
SEQUENCE:1 STEP:1 (USE +,-,=,CE)
SELECT MODE: VENT
If the step number is higher than 1, then:
[+]
SEQUENCE:1 STEP:n (USE +,-,=,CE)
SELECT MODE: LOOP
Press [=] for the desired mode. The second
parameter required for each step is depend-
ent on the selected mode; for CONTROL mode
a pressure setpoint is needed:
[+]
SEQUENCE:1 STEP:1 (USE =,CE)
ENTER SETPT: ? PSI G
[n...] The pressure units displayed will be the cur-
rently active units. Enter the CONTROL pres-
sure value for step 1, then press [=]:
