mensor PCS 400 - SPARE PARTS LIST

SPARE PARTS LIST
Below is a table showing PCS 400 spare parts that can be ordered from Mensor.
Table 5.2 – Spare Parts
*Recommended Spare Parts Note 1: Rev A for V1.XX software,
Rev B or higher for V2.XX software.
Note 2: Rev E for V1.XX software,
Rev F or higher for V2.XX software.
Note 3: Requires specific ranges and software
version number. Contact Mensor for exact
replacement.
Part Description Part Number Comments
Miscellaneous
Manual 0014141001
Fuses
* 4100111150
Power Cord 4000400002
Rubber Feet 3201300001
Front Panel Assembly
0014181001
Display Module 5000400012
Electrical Module
0014142001 Note 1
GPIB Board 4904000015
Solenoid Driver Board 0014172001
PLA Board 0014293001 Note 2
Floppy Drive 4907000002
Power Supply (modified) 4901000024
CMOS Backup Battery - 3.6 V 4100400014
CMOS Backup Battery - 6 V 4100400015
Pneumatics Module Note 3
HP Solenoid Valve Assembly (modified)
* 0014209002
HP Solenoid Valve Assembly (unmodified)
* 0012347012
LP Solenoid Valve Assembly (modified)
* 0014209001
LP Solenoid Valve Assembly (unmodified)
* 0012347011
Reed Valve Regulator Top Cap Assembly 0014266001 High Pressure
Reed Valve Regulator Top Cap Assembly 0014266002 Low Pressure
Pneumatic Filter Elements
* 6001202006
7/16-20 to 1/8" NPT female fittings 6000802004
O-ring seals for all 7/16-20 fittings
* 4250010020
7/16-20 to 1/4" Swagelok 6000604019
7/16-20 to 1/4" NPT female fittings 0012688001
