(Table 4.2 – Error Codes continued...)
Code
Serial
Poll
Byte
Description Error String Returned
E32 60h Invalid transducer selection INVALID TRANSDUCER SELECTION
E33 61h
Invalid filter window selection INVALID FILTER WINDOW SELECTION
E34 62h Invalid filter setting selection INVALID FILTER SETTING SELECTION
E35 63h Invalid output format selection NOT A VALID OUTPUT FORM SELECTION
E36 64h Invalid stable window selection INVALID STABLE WINDOW SELECTION
E37 65h Invalid stable delay selection INVALID STABLE DELAY SELECTION
E38 66h reserved unused code
E39 67h Expected a filter setting selection EXPECTED A FILTER SETTING SELECTION
E40 68h Expected an output format selection EXPECTED AN OUTPUT FORM SELECTION
E41 69h
Expected a stable delay selection EXPECTED A STABLE DELAY SELECTION
E42 6ah Expected a language selection EXPECTED A LANGUAGE SELECTION
E43 6bh reserved unused code
E44 6ch reserved unused code
E45 6dh PCS 200 command format error PCS200 COMMAND FORMAT ERROR
E46 6eh Control pressure overrange CONTROL PRESSURE OVERRANGE
E47 6fh Control pressure underrange CONTROL PRESSURE UNDERRANGE
E48 70h Illegal GPIB controller function ILLEGAL GPIB CONTROLLER FUNCTION
E49 71h
GPIB error GPIB ERROR
E50 72h Invalid termination INVALID TERMINATION
E51 73h Vent mode disabled VENT MODE DISABLED
E52 74h Special functions not available SPECIAL FUNCTIONS NOT AVAILABLE
E53 75h reserved unused code
E54 76h Expected a valid DPC-179 command EXPECTED A VALID DPC-179 COMMAND
E55 77h
Expected a valid DPC-179 header
command
EXPECTED A VALID DPC-179 HEADER
COMMAND
E56 78h
Expected a valid DPC-179 control
command
EXPECTED A VALID DPC-179 CONTROL
COMMAND
E57 79h reserved unused code
E58 7ah reserved unused code
E59 7bh reserved unused code
E60 7ch High Pressure Control Unit off HIGH PRESSURE CONTROL UNIT OFF
E61 7dh High Pressure Control Unit error HIGH PRESSURE CONTROL UNIT ERROR
E62 7eh reserved unused code
E63 7fh cal functions disabled CAL FUNCTIONS DISABLED
