Description Nm lb‑in. lb‑ft
Steering cable nut 47.5 – 35
a - Steering bracket screw and washer (2)
b - Steering cable seal
c - Steering cable nut
STEERING LINK ROD INSTALLATION
!
WARNING
Improper fasteners or improper installation procedures can result in
loosening or disengagement of the steering link rod. This can cause a
sudden, unexpected loss of boat control, resulting in serious injury or death
due to occupants being thrown within or out of the boat. Always use required
components and follow instructions and torque procedures.
IMPORTANT:The steering link rod that connects the steering cable to the
outboard must be fastened using the steering link rod fastening hardware
included with the outboard. Never replace the locknuts with non‑locking nuts.
Non‑locking nuts may loosen and vibrate off, allowing the link rod to disengage.
INSTALLATION
44 eng
