FRONT COWL LOWER PANEL INSTALLATION
1. Align the front cowl lower panel pins with the pin holes on the outboard.
76063
2. Install the front lower cowl on the outboard with the four short hex head
screws.
a - Short hex head screws (4)
b - Front cowl upper panel
3. Tighten the short hex head screws to the specified torque.
Description
Nm lb‑in. lb‑ft
Short hex head screws 3.3 29 –
aaaa
b
76045
INSTALLATION
eng 53 

Mercury Avator 7.5e Specifications

General

Power Source	Electric
Control	Tiller
Mounting	Transom
Operating Voltage	48V
Power	750W
Engine Type	Electric motor
Run Time	Up to 1 hour at full throttle
Propeller	3-blade
Warranty	2 years
Shaft Length	Short
